DC to DC Converter and Switching Regulator Module

THI 2-1211M

Module DC-DC 12VIN 1-OUT 5V 0.4A 2W 6-Pin DIP Module

Traco Power

Product Technical Specifications

• EU RoHS

  Compliant with Exemption

• ECCN (US)

  EAR99

• Part Status

  Active

• SVHC

  Yes

• SVHC Exceeds Threshold

  Yes

• Automotive

  Unknown

• PPAP

  Unknown

• Type

  Step Down

• Isolation

  Isolated

• Number of Outputs

  1

• Minimum Input Voltage (V)

  9

• Typical Input Voltage (V)

  12

• Maximum Input Voltage (V)

  13.2

• Output Voltage (V)

  5

• Output Current (A)

  0.4

• Output Power (W)

  2

• Minimum Isolation Voltage

  3000VAC

• Input/Output Type

  DC/DC

• Maximum Switching Frequency (kHz)

  50 to 100

• Switching Regulator

  Yes

• Load Regulation

  12%

• Line Regulation

  1.2%/1%Vi

• Efficiency (%)

  66(Typ)

• Minimum Operating Temperature (°C)

  -25

• Maximum Operating Temperature (°C)

  80

• Product Weight (g)

  5.1

• Output Type

  Fixed

• Mounting

  Through Hole

• Package Height

  8.6

• Package Width

  13.4

• Package Length

  23.8

• PCB changed

  6

• Standard Package Name

  DIP

• Supplier Package

  DIP Module

• Pin Count

  6

• Lead Shape

  Through Hole
