| EU RoHS | Supplier Unconfirmed |
| ECCN (US) | 5A992c. |
| Part Status | Unconfirmed |
| HTS | 8517.62.00.20 |
| Automotive | No |
| PPAP | No |
| Technology | IEEE 802.11a/b/g/n |
| Style | Chip |
| Modulation Technique | 16QAM|64QAM|BPSK|CCK|DBPSK|DQPSK|DSSS|OFDM|QPSK |
| Maximum Data Rate (Kbps) | 300000 |
| Band Mode | Dual |
| Maximum Operating Frequency (MHz) | 2400(Typ)|5000(Typ) |
| Interface | PCI |
| Typical Operating Supply Voltage (V) | 3.3 |
| Maximum Current Consumption (TX) (mA) | 580(Typ)|790(Typ) |
| Maximum Current Consumption (RX) (mA) | 160(Typ) |
| Wi-Fi Compliant | Yes |
| Wi-Fi Direct | No |
| Security | 802.11x/WEP/WPA/WPA2 |
| Operation Mode | Ad-Hoc|Client |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 85 |
| Mounting | Screw |
| Package Height | 3.45 |
| Package Width | 26.8 |
| Package Length | 29.85 |
