Inductor Surface Mount

SRP6050CA-4R7M

Inductor Power Shielded Wirewound 4.7uH 20% 100KHz Metal Alloy Powder 8.5A 0.0184Ohm DCR T/R Automotive AEC-Q200

Bourns

Product Technical Specifications

• EU RoHS

  Compliant

• ECCN (US)

  EAR99

• Part Status

  Active

• HTS

  8504.50.40.00

• Automotive

  Yes

• PPAP

  Yes

• Type

  Power

• Technology

  Wirewound

• Protection Style

  Shielded

• Core Material

  Metal Alloy Powder

• Inductance (H)

  4.7u

• Inductance Decrease Percentage @ Isat (%)

  30

• Tolerance

  20%

• Inductance Test Frequency (Hz)

  100K

• Maximum DC Current (A)

  8.5(Typ)

• Maximum Saturation Current (A)

  10.5(Typ)

• Maximum DC Resistance (Ohm)

  0.0184

• Minimum Self Resonant Frequency (Hz)

  22M(Typ)

• Number of Terminals

  2

• Minimum Operating Temperature (°C)

  -55

• Maximum Operating Temperature (°C)

  155

• Packaging

  Tape and Reel

• Maximum Product Length (mm)

  6.8

• Mounting

  Surface Mount

• Maximum Product Depth (mm)

  6.6

• Maximum Product Height (mm)

  5
