Product Technical Specifications
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8504.40.95.20
Automotive
No
PPAP
No
Type
Regulated
Style
Desktop Adapter
Input/Output Type
AC/DC
Number of Outputs
1
Output Type
Fixed
Output Voltage (V)
24
Output Current (A)
5
Output Power (W)
120
Minimum Isolation Voltage
3000VAC(Typ)
Typical Inrush Current (A)
80(Max)@230VAC
Maximum Input Current (A)
1.6
Input Frequency (Hz)
47 to 63
Input Connector Type
IEC 320 C14
Adapter Color
Black
Output Connector Type
DIN Female
Power Indicator
No
Ripple and Noise
240mV(Max)
Protection
Over Current|Over Temperature|Over Voltage|Short Circuit
Minimum Operating Temperature (°C)
-20
Maximum Operating Temperature (°C)
40
Packaging
Box
Product Weight (g)
336
Mounting
Desktop
Package Height
32
Package Width
51
Package Length
132
