MEAN WELLSD-100C-12DC to DC Converter and Switching Regulator Module
Module DC-DC 48VIN 1-OUT 12V 8.5A 102W 7-Pin
| Compliant | |
| EAR99 | |
| Active | |
| 8542.39.00.90 | |
| Automotive | No |
| PPAP | No |
| Step Down | |
| Isolated | |
| 1 | |
| 36 | |
| 48 | |
| 72 | |
| 12 | |
| 8.5 | |
| 102 | |
| 1500VAC | |
| DC/DC | |
| No | |
| 0.3% | |
| 0.3% | |
| 77(Typ) | |
| -10 | |
| 60 | |
| 650 | |
| Fixed | |
| Mounting | Desktop |
| Package Height | 38 mm |
| Package Width | 98 mm |
| Package Length | 199 mm |
| PCB changed | 7 |
| 7 |
The SD-100C-12 DC to DC power supply from Mean-Well USA, Inc. will adjust the input power supply to meet your projects' specifications. It has a voltage of 12 V. This part has an input voltage of 36 to 72 V. This part has a minimum operating temperature of -10 °C and a maximum of 60 °C.
