DC to DC Converter and Switching Regulator Module

PDQE30-Q48-S15-D

Module DC-DC 48VIN 1-OUT 15V 2A 30W 6-Pin DIP Module Tube

CUI Inc

Product Technical Specifications

• EU RoHS

  Compliant with Exemption

• ECCN (US)

  EAR99

• Part Status

  NRND

• HTS

  8542.39.00.01

• Automotive

  No

• PPAP

  No

• Type

  Step Down

• Isolation

  Isolated

• Number of Outputs

  1

• Minimum Input Voltage (V)

  18

• Typical Input Voltage (V)

  48

• Maximum Input Voltage (V)

  75

• Output Voltage (V)

  15

• Output Current (A)

  2

• Output Power (W)

  30

• Minimum Isolation Voltage

  1500VDC

• Input/Output Type

  DC/DC

• Maximum Switching Frequency (kHz)

  270(Typ)

• Switching Regulator

  Yes

• On/Off Logic

  Positive

• Minimum Operating Temperature (°C)

  -40

• Maximum Operating Temperature (°C)

  85

• Packaging

  Tube

• Output Type

  Fixed

• Mounting

  Through Hole

• Package Height

  11.7

• Package Width

  25.4

• Package Length

  25.4

• PCB changed

  6

• Standard Package Name

  DIP

• Supplier Package

  DIP Module

• Pin Count

  6
