Capacitor Aluminum Electrolytic

LNU2W562MSEJ

Cap Aluminum Lytic 5600uF 450V 20% (90 X 105mm) Bracket Mount Screw 19.6A 5000h 105°C

Nichicon

Product Technical Specifications

• EU RoHS

  Compliant

• ECCN (US)

  EAR99

• Part Status

  Active

• HTS

  8532.22.00.85

• Automotive

  No

• PPAP

  No

• Type

  Electrolytic

• Capacitance Value

  5600uF

• Tolerance

  20%

• Voltage

  450VDC

• IR (mA)

  19.6

• IL (uA)

  4760@5Min

• Lifetime (h)

  5000

• Polarity

  Polar

• Construction

  Aluminum Cylindrical Can

• Mounting

  Bracket Mount

• Termination Style

  Screw

• Number of Terminals

  2

• Size (mm)

  90 X 105

• Minimum Operating Temperature (°C)

  -40

• Maximum Operating Temperature (°C)

  105

• Product Diameter (mm)

  90

• Product Height (mm)

  105

• Product Weight (g)

  888

• Diameter Tolerance (mm)

  2

• Height Tolerance (mm)

  3
