AC to DC Power Supplies

LDT960-72

AC/DC Power Supply Single-OUT 72V 13.3A 960W 11-Pin

Bel Power Solutions

Product Technical Specifications

• ECCN (US)

  EAR99

• Part Status

  Obsolete

• HTS

  8504.40.95.30

• Automotive

  No

• PPAP

  No

• Type

  Switching

• Style

  DIN Rail

• Input/Output Type

  AC/DC

• Number of Outputs

  1

• Output Type

  Fixed

• Output Voltage (V)

  72

• Output Current (A)

  13.3

• Output Power (W)

  960

• Minimum AC Input Voltage (V)

  340

• Maximum AC Input Voltage (V)

  550

• Minimum DC Input Voltage (V)

  520

• Maximum DC Input Voltage (V)

  725

• Minimum Isolation Voltage

  4200VDC

• Load Regulation

  0.5%

• Maximum Input Current (A)

  2.4

• Input Frequency (Hz)

  47 to 63

• Efficiency (%)

  93(Min)

• Configurable

  No

• Input Connector Type

  Screw Terminal Block

• Output Connector Type

  Screw Terminal Block

• Power Indicator

  Yes

• Ripple and Noise

  100mV(Max)

• Medical

  No

• Minimum Operating Temperature (°C)

  -40

• Maximum Operating Temperature (°C)

  70

• Product Weight (g)

  1300

• Mounting

  DIN Rail

• Package Width

  80

• Package Length

  147.5

• PCB changed

  11

• Pin Count

  11
