AC to DC Power Supplies

KWS15A-24

AC/DC Power Supply Single-OUT 24V 0.7A 16.8W 4-Pin

TDK-Lambda

Product Technical Specifications

• EU RoHS

  Compliant with Exemption

• ECCN (US)

  EAR99

• Part Status

  Active

• HTS

  8504.40.95.10

• SVHC

  Yes

• SVHC Exceeds Threshold

  Yes

• Automotive

  No

• PPAP

  No

• Type

  Regulated

• Style

  Encapsulated

• Power Supply Color

  Black

• Input/Output Type

  AC/DC

• Number of Outputs

  1

• Output Type

  Fixed

• Output Voltage (V)

  24

• Output Current (A)

  0.7

• Output Power (W)

  16.8

• Minimum AC Input Voltage (V)

  85

• Typical AC Input Voltage (V)

  100|240

• Maximum AC Input Voltage (V)

  265

• Minimum DC Input Voltage (V)

  120

• Maximum DC Input Voltage (V)

  370

• Minimum Isolation Voltage

  3000VAC

• Line Regulation

  96mV

• Load Regulation

  150mV

• Maximum Input Current (A)

  0.33

• Input Frequency (Hz)

  47 to 440

• Tolerance (%)

  ±5

• Efficiency (%)

  85(Typ)

• Configurable

  No

• Input Connector Type

  PC Pins

• Output Connector Type

  PC Pins

• Power Indicator

  No

• Ripple and Noise

  240mV

• Medical

  No

• Minimum Operating Temperature (°C)

  -40

• Maximum Operating Temperature (°C)

  85

• Product Weight (g)

  60

• Mounting

  Through Hole

• Package Height

  24 mm

• Package Width

  50.8 mm

• Package Length

  25.4 mm

• PCB changed

  4

• Pin Count

  4
