Product Technical Specifications
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8541.29.00.55
Automotive
No
PPAP
No
Category
Power MOSFET
Configuration
Single
Channel Mode
Enhancement
Channel Type
N
Number of Elements per Chip
1
Maximum Drain-Source Voltage (V)
600
Maximum Gate-Source Voltage (V)
20
Operating Junction Temperature (°C)
-55 to 150
Maximum Continuous Drain Current (A)
18
Maximum Drain-Source Resistance (mOhm)
180@10V
Typical Gate Charge @ Vgs (nC)
17@10V
Typical Input Capacitance @ Vds (pF)
743@400V
Maximum Power Dissipation (mW)
127000
Typical Fall Time (ns)
12.8
Typical Rise Time (ns)
6
Typical Turn-Off Delay Time (ns)
88.4
Typical Turn-On Delay Time (ns)
17.2
Minimum Operating Temperature (°C)
-55
Maximum Operating Temperature (°C)
150
Mounting
Surface Mount
Package Height
2.3
Package Width
6.22
Package Length
6.5
PCB changed
2
Tab
Tab
Standard Package Name
TO
Supplier Package
DPAK
Pin Count
3
