TFT Modules

HIA800480T013IHC09

i.MX8M 7in TFT WVGA 800x480Pixels MIPI DSI/RGB 850cd/m2 LCD Backlight -20°C to 70°C

Powertip Technology

Product Technical Specifications

• EU RoHS

  Compliant

• ECCN (US)

  EAR99

• Part Status

  Active

• HTS

  8528.59.33.70

• Automotive

  Unknown

• PPAP

  Unknown

• Display Mode

  Normally White-Transmissive

• Display Size (in)

  7

• Pixel Format (Pixels)

  800x480

• Resolution Standard

  WVGA

• Aspect Ratio

  5:3

• Typical Contrast Ratio

  600:1

• Typical Brightness (cd/m2)

  850

• Backlight

  LCD

• Viewing Angle (°)

  120/120

• Touchscreen

  Yes

• Active Area (mm)

  154.08x85.92

• Outline Dimensions (mm)

  118.1x87x25

• Typical Response Time (ms)

  25

• Interface Type

  MIPI DSI|RGB

• Minimum Operating Temperature (°C)

  -20

• Maximum Operating Temperature (°C)

  70

• Mounting

  Panel

• Package Height

  5.29

• Package Width

  110.56

• Package Length

  186.8
