FC1-10-02-T-WT

Conn FFC Connector SKT 10 POS 1mm Solder RA SMD Tube

Samtec

Product Technical Specifications

• EU RoHS

  Compliant

• ECCN (US)

  EAR99

• Part Status

  Active

• HTS

  8536.69.40.40

• Automotive

  No

• PPAP

  No

• Type

  FFC Connector

• Number of Contacts

  10

• Number of Rows

  1

• Termination Method

  Solder

• Terminal Pitch (mm)

  1

• Body Orientation

  Right Angle

• Contact Gender

  SKT

• Maximum Current Rating (A)

  2/Contact

• Maximum Voltage Rating

  300VAC|424VDC

• Insulation Resistance (MOhm)

  1000

• Maximum Contact Resistance (mOhm)

  15

• Minimum Operating Temperature (°C)

  -55

• Maximum Operating Temperature (°C)

  105

• Mating Cycle (Cycles)

  25

• Packaging

  Tube

• Product Length (mm)

  12.34

• Product Depth (mm)

  6.22

• Product Height (mm)

  2.77

• Mounting

  Surface Mount
