Product Technical Specifications
EU RoHS
Compliant
ECCN (US)
EAR99
Part Status
Active
HTS
8541.41.00.00
Automotive
No
PPAP
No
Type
Uni-Color
Category
Chip LED
Color
Ultraviolet
Number of LEDs
1
Lens Shape Type
Circular
Mounting Orientation
Top Mount
Peak Wavelength (nm)
400(Max)
Viewing Angle (°)
120
Maximum Forward Current (mA)
700
Test Current (mA)
500
Maximum Forward Voltage (V)
3.85
Maximum Power Dissipation (mW)
3000
Minimum Operating Temperature (°C)
-40
Maximum Operating Temperature (°C)
110
Lead Standoff
No
Supplier Color
Ultraviolet
Special Color
Ultraviolet
High Power
Yes
High Brightness
Yes
Packaging
Tape and Reel
Mounting
Surface Mount
Package Width
3.5
Package Length
3.5
PCB changed
2
Supplier Package
CSMD EP
Pin Count
2
