Connector Headers and PCB Receptacles

DW-02-19-T-Q-1110-001

Conn Board Stacker HDR 4 POS 2.54mm Solder ST Top Entry Thru-Hole Bulk

Samtec

Product Technical Specifications

• EU RoHS

  Compliant

• ECCN (US)

  EAR99

• Part Status

  Active

• HTS

  8536.69.40.40

• Automotive

  No

• PPAP

  No

• Type

  Board Stacker

• Gender

  HDR

• Number of Contacts

  4

• Number of Rows

  3

• Termination Method

  Solder

• Terminal Pitch (mm)

  2.54

• Body Orientation

  Straight

• Row Spacing (mm)

  5.08

• Maximum Current Rating (A)

  3/Contact

• Minimum Operating Temperature (°C)

  -55

• Maximum Operating Temperature (°C)

  105

• Packaging

  Bulk

• Product Length (mm)

  5.08

• Product Depth (mm)

  7.52

• Product Height (mm)

  30.99

• Tail Length (mm)

  2.79

• Mounting

  Through Hole
