DC to DC Converter and Switching Regulator Module

DJ06S2405A

Module DC-DC 24VIN 1-OUT 5V 1.2A 6W 7-Pin PDIP

Delta Electronics

Product Technical Specifications

• EU RoHS

  Compliant

• ECCN (US)

  EAR99

• Part Status

  Active

• HTS

  8542.39.00.60

• Automotive

  No

• PPAP

  No

• Type

  Step Down

• Isolation

  Isolated

• Number of Outputs

  1

• Minimum Input Voltage (V)

  9

• Typical Input Voltage (V)

  24

• Maximum Input Voltage (V)

  36

• Output Voltage (V)

  5

• Output Current (A)

  1.2

• Output Power (W)

  6

• Minimum Isolation Voltage

  1500VDC

• Maximum Switching Frequency (kHz)

  330(Typ)

• Switching Regulator

  Yes

• Load Regulation

  1.2%

• Line Regulation

  0.5%

• Efficiency (%)

  80(Typ)

• Minimum Operating Temperature (°C)

  -40

• Maximum Operating Temperature (°C)

  85

• Product Weight (g)

  12.7

• Output Type

  Fixed

• Mounting

  Through Hole

• Package Height

  10.2

• Package Width

  20.3

• Package Length

  31.8

• PCB changed

  7

• Standard Package Name

  DIP

• Supplier Package

  PDIP

• Pin Count

  7

• Lead Shape

  Through Hole
