Connector Headers and PCB Receptacles

878331820

Conn Shrouded Header (4 Sides) HDR 18 POS 2mm Solder RA Side Entry Thru-Hole Milli-Grid Tube

Molex

Product Technical Specifications

• EU RoHS

  Compliant

• ECCN (US)

  EAR99

• Part Status

  Active

• Automotive

  No

• PPAP

  No

• Type

  Shrouded Header (4 Sides)

• Gender

  HDR

• Number of Contacts

  18

• Number of Rows

  2

• Termination Method

  Solder

• Terminal Pitch (mm)

  2

• Body Orientation

  Right Angle

• Polarization Type

  Center Slot/Dual Slot

• Row Spacing (mm)

  2

• Maximum Current Rating (A)

  2/Contact

• Maximum Voltage Rating

  125V

• Insulation Resistance (MOhm)

  1000

• Maximum Contact Resistance (mOhm)

  40

• Minimum Operating Temperature (°C)

  -55

• Maximum Operating Temperature (°C)

  105

• Mating Cycle (Cycles)

  50

• Packaging

  Tube

• Product Weight (g)

  0.958

• Product Length (mm)

  20.65

• Product Depth (mm)

  8.65

• Product Height (mm)

  6.3

• Tradename

  Milli-Grid

• Mounting

  Through Hole
