HARTING Technology Group14310313101000Connector Terminal Blocks
Connector Terminal Block, Spring Cage F 3 POS 2.54mm ST Cable Mount 6A
| Compliant | |
| EAR99 | |
| Active | |
| 8536.69.40.40 | |
| Automotive | No |
| PPAP | No |
| 3 | |
| 2.54 | |
| 3 | |
| Push-In Cage Clamp | |
| 6 | |
| 160V | |
| 1000 | |
| Black |
Know that you will have strong connections between circuits when you use Harting's spring cage terminal block 14310313101000 PCB terminal block. This F connector's 3 contacts that are made out of copper alloy and plated with tin. It has a female type gender. This is a 1-row connector. It has a straight body orientation. Its pitch is 2.54 mm. It has a maximum voltage rating of 160 V. 14310313101000 is housed in liquid crystal polymer. This device has a maximum current rating of 6 A. Its wire is 20-24 AWG. This product is 12.92 mm long, 4.9 mm tall and 14.2 mm deep. This quick disconnect terminal has an operating temperature of -40 to 125 °C.
