Connector D-Subminiature

09565005615050

Conn D-Sub M 78 POS 1.21mm Solder Cup ST Panel Mount 78 Terminal 1 Port

HARTING Technology Group

Product Technical Specifications

• EU RoHS

  Compliant

• ECCN (US)

  EAR99

• Part Status

  Active

• HTS

  8536.69.40.30

• Automotive

  No

• PPAP

  No

• Type

  D-Sub

• Gender

  PL

• Number of Contacts

  78

• Number of Terminals

  78

• Number of Ports

  1

• Number of Rows

  4

• Termination Method

  Solder Cup

• Terminal Pitch (mm)

  1.21

• Body Orientation

  Straight

• Contact Gender

  M

• Maximum Current Rating (A)

  2

• Insulation Resistance (MOhm)

  5000

• Maximum Contact Resistance (mOhm)

  20

• Minimum Operating Temperature (°C)

  -40

• Maximum Operating Temperature (°C)

  85

• Mating Cycle (Cycles)

  500

• Shell Material

  Steel

• Shell Plating

  Nickel

• Shell Size

  D

• Product Length (mm)

  67

• Product Height (mm)

  12.55

• Contact Plating

  Noble Metal Over Nickel

• Contact Material

  Copper Alloy

• Mounting

  Panel Mount
