DC-DC 변환기 및 스위칭 레귤레이터 모듈

THN 10-2410WIR

Module DC-DC 24VIN 1-OUT 3.3V 3A 10W 6-Pin

Traco Power

제품 기술 사양

• 유럽 연합 RoHS 명령어

  Compliant with Exemption

• 미국수출통제분류ECCN 인코딩

  EAR99

• 친환경 무연

  Active

• 미국 세관 상품 코드

  8504.40.95.10

• SVHC

  Yes

• SVHC 기준 초과

  Yes

• Automotive

  Unknown

• PPAP

  Unknown

• Type

  Step Down

• Number of Outputs

  1

• Isolation

  Isolated

• Minimum Input Voltage (V)

  9

• Typical Input Voltage (V)

  24

• Maximum Input Voltage (V)

  36

• Output Voltage (V)

  3.3

• Output Current (A)

  3

• Output Power (W)

  10

• Minimum Isolation Voltage

  3000VDC

• Input/Output Type

  DC/DC

• Typical Standby Current (mA)

  2.5

• Maximum Switching Frequency (kHz)

  320

• Switching Regulator

  Yes

• Load Regulation

  0.2%

• Line Regulation

  0.2%

• Efficiency (%)

  87(Typ)

• On/Off Logic

  Positive

• Minimum Operating Temperature (°C)

  -40

• Maximum Operating Temperature (°C)

  95

• Product Weight (g)

  16.5

• Output Type

  Fixed

• Mounting

  Through Hole

• Package Height

  9.9

• Package Width

  25.4

• Package Length

  25.4

• PCB changed

  6

• Pin Count

  6
