Conectores de Telecomunicaciones y teléfono

MRJR334001

Conn RJ-11 RCP 4 POS 2.54mm Solder RA Thru-Hole 8 Terminal 1 Port

Amphenol Communications Solutions

Especificaciones técnicas del producto

• RoHS (Unión Europea)

  Compliant

• ECCN (Estados Unidos)

  EAR99

• Estatus de pieza

  Active

• Automotive

  No

• PPAP

  No

• Type

  RJ-11

• Gender

  RCP

• Number of Terminals

  8

• Number of Contacts

  4

• Number of Ports

  1

• Number of Loaded Positions

  4

• Termination Method

  Solder

• Terminal Pitch (mm)

  2.54

• Body Orientation

  Right Angle

• Maximum Current Rating (A)

  1.5

• Insulation Resistance (MOhm)

  500

• Maximum Contact Resistance (mOhm)

  30

• Integrated Magnetics

  No

• Shell Material

  Die Cast Zinc

• Shell Plating

  Nickel

• Minimum Operating Temperature (°C)

  -40

• Maximum Operating Temperature (°C)

  105

• Product Style

  Single

• Product Length (mm)

  30.3

• Product Depth (mm)

  28.32

• Product Height (mm)

  18

• Mounting

  Through Hole
