VishayMAL215937101E3Capacitor Aluminum Electrolytic
Cap Aluminum Lytic 100uF 450V 20% (22 X 40mm) Snap-In 10mm 1.8 Ohm 0.74A 5000h 105°C Bulk
| Compliant | |
| EAR99 | |
| Active | |
| 8532.22.00.40 | |
| Automotive | No |
| PPAP | No |
| Electrolytic | |
| 100uF | |
| 20% | |
| 450VDC | |
| 1.8 | |
| Low | |
| 1.05@20°C@10kHz | |
| 0.74 | |
| 450@5Min | |
| 5000 | |
| Polar | |
| High Ripple Current|Low ESR|Non-Solid Electrolyte|Polarized Aluminum Electrolytic | |
| Aluminum Cylindrical Can | |
| Through Hole | |
| Snap-In | |
| 2 | |
| 10 | |
| 22 X 40 | |
| -25 | |
| 105 | |
| Bulk | |
| 22 | |
| 40 | |
| 23 |
The pure aluminum anode on the electrolytic MAL215937101E3 electrolytic capacitor, designed from Vishay, is the solution to your signal filtering needs. It can withstand a voltage of 450 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. Its capacitance value is 100uF. It has a tolerance of 20%. This product is 40 mm tall with a diameter of 22 mm. The MAL215937101E3 aluminum electrolytic capacitor has a snap-in termination style. Its leakage current is 450@5Min μA. This part has a pitch of 10 mm.
