VishayIHLP2525CZER4R7M11Inductor Surface Mount
Power Choke Shielded Wirewound 4.7uH 20% 100KHz Powdered Iron 6A 0.0334Ohm DCR 2525 T/R
| Compliant | |
| EAR99 | |
| Active | |
| COMPONENTS | |
| Automotive | No |
| PPAP | No |
| Power Choke | |
| Wirewound | |
| Shielded | |
| Powdered Iron | |
| 4.7u | |
| 20% | |
| 100K | |
| 6(Typ) | |
| 4(Typ) | |
| 0.0334 | |
| 2 | |
| 2525 | |
| -55 | |
| 125 | |
| Tape and Reel | |
| 7.24 | |
| Surface Mount | |
| 6.72 | |
| 3 |
Save valuable space on a PCB with this power IHLP2525CZER4R7M11 surface mount inductor from Vishay. This SMD inductor has an operating temperature range of -55 °C to 125 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This device utilizes wirewound technology. It has an inductance of 4.7u H. This SMD inductor has a maximum DC current of 6(Typ) A with a maximum resistance of 31.8m Ohm. It has a tolerance of 20%. This product is 7.24 mm long, 3 mm tall and 6.72 mm deep. Its test frequency is 100K Hz.
