Alpha and Omega SemiconductorAOD609MOSFETs
Trans MOSFET N/P-CH 40V 12A 5-Pin(4+Tab) DPAK T/R
| Compliant | |
| EAR99 | |
| Active | |
| 8541.29.00.95 | |
| Automotive | Unknown |
| PPAP | Unknown |
| Power MOSFET | |
| Dual Common Drain | |
| Enhancement | |
| N|P | |
| 2 | |
| 40 | |
| ±20 | |
| 3 | |
| 12 | |
| 100 | |
| 1 | |
| 30@10V@N Channel|45@10V@P Channel | |
| 8.3@10V@N Channel|16.2@10V|7.2@4.5V@P Channel | |
| 8.3@N Channel|16.2@P Channel | |
| 516@20V@N Channel|900@20V@P Channel | |
| 2000 | |
| 6.6@N Channel|41.2@P Channel | |
| 3.6@N Channel|8.4@P Channel | |
| 16.2@N Channel|44.8@P Channel | |
| 6.4@N Channel|6.2@P Channel | |
| -55 | |
| 175 | |
| Tape and Reel | |
| Mounting | Surface Mount |
| Package Height | 2.29 mm |
| Package Width | 6.1 mm |
| Package Length | 6.6 mm |
| PCB changed | 4 |
| Tab | Tab |
| Standard Package Name | TO |
| Supplier Package | DPAK |
| 5 |
Thanks to Alpha & Omega Semiconductor, both your amplification and switching needs can be taken care of with one component: the AOD609 power MOSFET. Its maximum power dissipation is 27000@N Channel|30000@P Channel mW. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This MOSFET transistor has a minimum operating temperature of -55 °C and a maximum of 175 °C. This device is made with tmos technology. This N|P channel MOSFET transistor operates in enhancement mode.
