Connector Headers and PCB Receptacles

803-43-004-20-001000

Conn Socket Strip SKT 4 POS 2.54mm Solder RA Side Entry Thru-Hole

Mill-Max

Product Technical Specifications

• EU RoHS

  Compliant with Exemption

• ECCN (US)

  EAR99

• Part Status

  Active

• HTS

  8536.69.40.40

• SVHC

  Yes

• SVHC Exceeds Threshold

  Yes

• Automotive

  No

• PPAP

  No

• Type

  Socket Strip

• Gender

  SKT

• Number of Contacts

  4

• Number of Rows

  2

• Termination Method

  Solder

• Terminal Pitch (mm)

  2.54

• Body Orientation

  Right Angle

• Row Spacing (mm)

  2.54

• Maximum Current Rating (A)

  3

• Maximum Voltage Rating

  100VAC|150VDC

• Insulation Resistance (MOhm)

  10000

• Maximum Contact Resistance (mOhm)

  10

• Minimum Operating Temperature (°C)

  -55

• Maximum Operating Temperature (°C)

  125

• Mating Cycle (Cycles)

  100

• Product Length (mm)

  5.08

• Product Depth (mm)

  10.84

• Product Height (mm)

  5.08

• Tail Length (mm)

  3.2

• Mounting

  Through Hole
